LIHAT BROSUR : Brosur Total Station Topcon GM 50 Series
Topcon GM-50 Series yaitu alat instrumen optis/elektronik yang lengkap dapat mengukur sudut dan jarak sehingga dapat digunakan dalam pemetaan dan kontruksi dan bangunan. Total station merupakan alat terintegrasi dengan komponen pengukur jarak elektronik (electronic distance meter (EDM)) untuk membaca jarak dan kemiringan dari instrumen ke titik tertentu.
Alat ini merupakan produk Topcon terbaru pada jenis Total Station dengan beberapa fitur unggulan. Topcon GM-50 Series ini sangat membantu para Surveyor dalam kerja lapangan karna menghasilkan hasil yang terbukti akurat.
Total Station Topcon dari Seri GM mempunyai kinerja yang sangat memuaskan bagi para pengguna dalam pengukuran di lapangan. Dengan keakuratan hasil pengukuran yang sangat baik dan tepat. Seri Total Station Topcon GM ini mempunyai akurasi 2 detik dan 5 detik yang sangat membantu ketika pengukuran di lapangan.
Total Station Seri GM banyak di gandrungi para surveyor karena ke akuratan hasil yang sangat baik. Dari semua Seri Total Station Topcon Hanya Seri Total Station Topcon GM yang sangat baik dalam hasil pengukuran di lapangan.
Spesifikasi Total Station Topcon GM-50 Series
-
- Akurasi 2 Detik (GM-52) dan 5 Detik (GM-55)
- Laser
- 2 Display (GM-52) dan 1 Display (GM-55)
- Daya tahan baterai 14 jam
- Bisa menggunakan flashdisk max 32 GB
- USB 2.0
- Bluetooth
- Reflectorless 0,3 meter sampai 500 meter
- Reflective sheet 1,3 meter sampai 500 meter
- Mini prisma 1,3 meter sampai 500 meter
- One Prisma 1,3 meter sampai 4000 meter
-
Telescope
-
- Magnification / Resolving power | 30x / 2.5
- Others | Length : 171mm (6.7in.)
- Objective aperture : 45mm (1.8in.) (48mm (1.9in.) for EDM)
- Image: Erect
- Field of view: 1°30′ (26m/1,000m)
- Minimum focus: 1.3m (4.3ft.)
- Reticle illumination: 5 brightness levels
-
Angle Measurement
-
- Minimum Display (selectable) | 1”/5” (0.0002 / 0.001gon, 0.005 / 0.02mil)
- Accuracy (ISO 17123-3:2001) | 2 | 5
- Dual-axis compensator | Dual-axis liquid tilt sensor
- working range: ±6′
- Collimation compensation | On/Off (selectable)
-
Distance Measurement
-
- Laser output*1 | Reflectorless mode : Class 3R / Prism/sheet mode : Class 1
- Measuring range(under average conditions*2)
- Reflectorless*3 | 0.3 to 500m (1,640ft.)
- Reflective sheet*4*5 | RS90N-K: 1.3 to 500m (4.3 to 1,640ft.),RS50N-K: 1.3 to 300m (4.3 to 980ft.),RS10N-K: 1.3 to 100m (4.3 to 320ft.)
- Mini prisms | 1.3 to 500m (4.3 to 1,640ft.)
- One prism | 1.3 to 500m (4.3 to 1,640ft.)
- Minimum Display |
- Fine / Coarse : 0.0001m (0.001ft. / 1/8 in.) / 0.001m (0.005ft. / 1/8 in.) (selectable)
- Coarse : 0.001m (0.005ft. / 1/8 in.) / 0.01m (0.02ft. / 1 in.) (selectable)
- Tracking / Road : 0.01m (0.02ft. / 1 in.)
- Accuracy*2(ISO 17123-4:2001)(D=measuring distance in mm)
- Reflectorless*3 | (2 + 2ppm x D) mm*6
- Reflective sheet*4*5 | (2 + 2ppm x D) mm
- Prism*7 | (1.5 + 2ppm x D) mm
- Measuring time*8
- Fine | 0.9s (initial 1.5s)
- Rapid | 0.6s (initial 1.3s)
- Tracking | 0.4s (initial 1.3s)
-
OS, Interface and Data Management
-
- Operating system | Linux
- Display / Keyboard | Graphic LCD, 192 x 80 dots, backlight : on/off (Selectable) / Alphanumeric keyboard / 28 keys with backlight
- Control panel location | On both faces | On single face
- Data storage
- Internal memory | Approx. 50,000 points
- Plug-in memory device | USB flash memory (max. 32GB)
- Interface | Serial RS-232C, USB2.0 (Type A for USB flash memory)
- Bluetooth modem (option) | Bluetooth Class 1.5, Operating range: up to 10m
-
General
-
- Laser-pointer | Coaxial red laser using EDM beam
- Levels
- Graphic | 6’ (Inner Circle)
- Circular level (on tribrach) | 10′ / 2mm
- Plummet
- Optical | Magnification: 3x, Minimum focus: 0.5m (19.7in.) from tribrach bottom
- Laser (option) | Red laser diode (635nm±10nm), Beam accuracy: <=1.0mm@1.3m, Class 2 laser product
- Dust and water protection / Operating temperature | IP66 (IEC 60529:2001) / -20 to +60ºC (-4 to +140ºF)
- Size with handle | 183(W)x 181(D)x 348(H)mm (On both faces) | 183(W)x 174(D)x 348(H)mm (On single face)
- Instrument height | 192.5mm from tribrach mounting surface
- Weight with battery & tribrach | Approx. 5.1kg (11.3lb)
-
Power Supply
-
- Battery | Li-ion rechargeable battery BDC46C
- Operating time (20ºC)*9 | Approx. 14hours
-
Application program
-
- On board
- REM Measurement
- 3D Coordinate Measurement
- Resection
- Stake Out
- Topography Observation
- Offset Measurement
- Missing Line Measurement
- Surface Area Calculation
- Route Surveying
- Point to Line
- On board
Kelengkapan
- 2 Unit Alumunium Tripod
- 1 Unit Prisma Polygon
- 1 Unit Prisma Single
- 1 Unit Pole/stick
- 1 Unit Charger
- 1 Unit Batery
- 1 Unit Kabel Data
- 1 CD Software
- Sertifikat Kalibrasi
- Kartu Garansi
Keuntungan beli Total Station di Indosurta Makassar
- Bergaransi servis dan kalibrasi 1 tahun
- Gratis training alat
- Gratis pengiriman dan juga COD khusus Makassar dan sekitarnya
